Virtual Reality Viewer: New version offers even more scope for creativity

i4 VIRTUAL REVIEW: The new version of the VR Viewer offers even more comfort for a comprehensive VR experience. Convince now.

Cambridge, UK and Pittsford, NY – 5 June 2019: Work with even larger 3D models, powerful new tools, and greater flexibility in virtual reality (VR). The new version of the i4 VIRTUAL REVIEW VR viewer is now available.

Easily move individual model parts in virtual reality

Higher performance for a better VR experience

With the new version of the i4 VIRTUAL REVIEW virtual reality viewer , it is now possible to load and fluidly display even larger and more detailed 3D buildings and CAD models in VR. This is made possible by the addition of full support for 64 bit systems.

i4 VIRTUAL REVIEW for extensive design data in Virtual Reality

A tape measure for the virtual world

When reviewing a design in VR it is very useful to be able to make measurements. This is now possible in i4 VIRTUAL REVIEW with the new measurement tool. Using the tool, distances between points can be quickly and easily measured by snapping dimensions to the edges of the model or the XYZ axes. Dimensions can be displayed in metres or millimetres.

Add notes and take screenshots

The new version of i4 VIRTUAL REVIEW now includes a mark-up tool. With this tool, notes and sketches can be drawn directly in VR. When using VR glasses the virtual environment effectively becomes a huge sketchpad. The mark-up tool provides a completely new way to review and provide feedback on designs by annotating them with notes and sketches in VR. The user draws lines of varying thickness and colour using a marker pen in VR. The new screenshot tool in i4 VIRTUAL REVIEW enables the user to take easily pictures of the current VR scene using a virtual camera. The pictures are then saved to disk as image files and can be subsequently used for documentation or even sales and marketing purposes.

Move model parts even easier

The Move tool is one of the most important tools in i4 VIRTUAL REVIEW. It is used whenever you want to move, rotate or hide something in VR. In the new version, the Move tool has been enhanced. Models can now be moved either by hand or by a given distance. Similarly, a model can be rotated by a specified angle. The distances and angles can be freely adjusted. The structure of the model is also taken into account when moving it, so that you can choose to move only part of the model, or the entire model.

A measuring tape for the virtual world with i4 VIRTUAL REVIEW

Support for Additional 3D formats

The new version of i4 VIRTUAL REVIEW enables textured models to be loaded directly into VR. This means that individual scenes and models can now be visualised even more realistically, further enhancing the immersive experience. In addition, models in OBJ format can now be loaded. This popular format is supported by many CAD systems. For models in STEP format, CAD Schroer offers a STEP to FBX converter. This includes the option of simplifying STEP models before automatically converting them to FBX format. The degree of simplification can also be specified for each model.

With the new version of the VR Viewer, designers can immerse themselves even more easily within their CAD designs.
